Audi A6 Typ 4G: Unlocking/locking by remote control
.88.png)
Fig. 18 Remote control key: button programming
If the vehicle is unlocked and none of the doors,
the rear lid or hood are opened within 60 seconds,
the vehicle locks again automatically. This
feature prevents the vehicle from being accidentally
left unlocked over a long period of time.
The settings in the Infotainment system determine
if the entire vehicle or only the driver's door
is unlocked when unlocking the vehicle.
WARNING
Read and heed all WARNINGS
.
Tips
- Only use the remote control key when you
are within view of the vehicle.
- The vehicle can only be locked when the selector
lever is in the P position.
- Do not use the remote control when you are
inside the vehicle. Otherwise, you could unintentionally
lock the vehicle. If you then
tried to start the engine or open a door, the
alarm would be triggered. If this happens,
press the
unlock button.
- Only use the panic function in an emergency.
